Another MAX

Boeing has formally launched a fourth variant of the 737 MAX range, as Mark Broadbent reports

This has been a big year for the Boeing 737. April marked 50 years since the initial 737 was delivered. In the same month, the first 737 MAX 9 undertook its maiden flight and entered testing. Then May saw the service entry of the 737 MAX 8 with Malindo Air (to be rebranded Batik Air Malaysia).

There was further significance to the year on the opening morning of the 52nd International Paris Air Show at Le Bourget on June 19, when Boeing formally launched the 737 MAX 10. This is the fourth major variant in the latest generation of the enduring airliner design alongside the 737 MAX 7, 737 MAX 8 and 737 MAX 9.

The 737 MAX 10’s maiden flight is scheduled for 2019, with first deliveries in 2020. The year 2019 will also see initial deliveries of the 737 MAX 7, which is due to fly in 2018. Next year will see the first 737 MAX 9 delivery. Handover of the 737 MAX 200, a high-density subvariant of the 737 MAX 8, is expected in 2019.


Length: 143ft 8in (43.8m)

Wingspan: 117ft 10in (35.9m)

Height: 40ft 3in (12.3m)

Interior cabin width: 11ft 7in (3.53m)

Body cabin width: 12ft 3in (3.73m)

Max take-off weight: 197,000lb (89,750kg)

Max fuel capacity: 7,638 US gallons (27,891 litres) with one auxiliary tank

Engines: Two CFM International LEAP-1Bs each rated at 27,900lb (124kN)

Seats: 230 one class, 188 two class

Cargo volume: 1,961ft3 (55.5m3)

Range: 3,215nm (5,955km)

Data: Boeing

The Aircraft

The 737 MAX 10 is a stretched derivative of the 737 MAX 9. It will have the same 117ft 10in (35.9m) wingspan as all the other family variants, but at 143ft 8in (43.8m) it will be 66 inches (1,676mm) longer than the 737 MAX 9. The extra length comes from two more fuselage barrels, one 40-inch (1,016mm) barrel fore of the wings and one 26-inch (660mm) barrel aft of the wings. Range will be 3,215nm (5,955km)

The extra length will give two extra rows of seating, meaning the 737 MAX 10 will be able to seat 230 passengers in a single-class layout or 188 passengers in a two-class layout. This compares to 162 seats one class in the 737 MAX 8 and 178 seats one class in the 737 MAX 9, and is up from the maximum 220 seats of the 737 MAX 200 that until the 737 MAX 10’s launch was the highest-density seating option available in the family.

Changes from the 737 MAX 9 are a variable exit limit rating mid-exit door added to the fuselage, a lighter flat aft pressure bulkhead, a modified wing for low-speed drag reduction, a modified landing gear and a slightly modified wing to accommodate the revised gear. The aircraft will be powered by a higher-thrust version of the CFM International LEAP-1B engine that powers all 737 MAX variants.

The landing gear required modification because the 737 MAX 10’s slightly extra length requires greater ground clearance when the aircraft rotates or lands. The gear will be semi-levered, a feature first developed by Boeing in the early 2000s for the 777-300ER. A semi-levered gear shifts the centre of rotation rearwards from the main axle on the main landing gear to the aft axle, which creates the required ground clearance to avoid a tailstrike.

United Airlines will receive 100 737 MAX 10s, although these orders have been switched to the variant from the smaller 737 MAX 8.
All photos Boeing
Boeing has secured 361 orders for the 737 MAX 10, which will be able to accommodate up to 230 passengers.

Like its family stablemates, the 737 MAX 10 will feature Advanced Technology winglets and the Boeing Sky Interior as standard.

Boosting Capacity

Boeing announced 361 commitments for the 737 MAX 10 during Paris, comprising firm orders, purchase commitments and memorandums of understanding that are yet to be firmed.

The largest single order was for 100 examples from United Airlines. Other major commitments came from the Lion Air Group (50) and SpiceJet (40), with a clutch of carriers (mainly from the Asia-Pacific region) and leasing companies making up the remainder of customers.

The orders for the 737 MAX 10 announced at Le Bourget may not be the only ones in the pipeline for the variant. Before the show, Ryanair said it is currently evaluating the 737 MAX 10.

Andrew Levy, United Airlines Executive Vice-President and Chief Financial Officer, said of United’s 100-aircraft order: “The 737 MAX 10 will enable us to continue using larger and more efficient aircraft within our domestic network.”

Levy’s comment goes to the heart of the business case underpinning the 737 MAX 10: capacity. A big trend among operators in the single-aisle airliner market in the last few years is ordering aircraft with more seats.

This up-gauging trend stems from industry economics: more seats maximises load factors, reduces seat-mile costs and increases revenues. The 737 MAX 10’s launch is partly to take advantage of that.

But it is also an attempt by Boeing to regain lost ground at the top end of the seating scale in the narrowbody aircraft market. The Airbus A321, the largest A320 Family variant, which seats 185 passengers two class or 236 single class, has sold like hot cakes in recent years in both its A320ceo and A320neo guises.

Against the more than 1,700 A321ceos and 1,400 A321neos that had been sold by Airbus to the start of July, sales of Boeing’s direct competitors to these aircraft, respectively the 737-900ER and 737 MAX 9, are less impressive. Boeing’s orders data shows just 510 737- 900ERs have been sold, and only a couple of hundred 737 MAX 9s have been ordered. Boeing claims the 737 MAX 10 will beat the A321neo’s performance by offering 5% lower trip costs and 5% lower seat-mile costs than its competitor.

Verbal sparring between Airbus and Boeing is a longstanding feature of the big trade air shows, so it was inevitable Airbus Chief Operating Officer Customers John Leahy noted how many 737 MAX 10 announcements involved customers shifting existing orders from other 737 MAX variants.

Of the 361 orders for the 737 MAX 10 announced during the Le Bourget week, 208 (or 57.6%) – including the big order from United and part of the order from Indian carrier SpiceJet – were actually conversions to the new variant from existing orders for other 737 MAX variants. The number of incremental orders for the 737 MAX 10 announced during the show – orders that increase the overall 737 MAX backlog rather than being moved from other variants – therefore stood at 153.

This is obviously slightly less attentiongrabbing from a PR perspective than the headline figure of 361. In saying that, up-gauging happens at Airbus, too – for example, this spring saw easyJet switch 40 of its A320neo orders to A321neos.

The key for all aircraft manufacturers is to position their products to meet changing market needs. Whether customers are new to a type or convert from another variant, the real significance of the 737 MAX 10’s launch is it further underlines the trend for larger single-aisle airliners.
